86J18118EC-1000-LS-60-YJ
JMC 86J18118EC-1000-LS-60-YJ 2-Phase Closed Loop Stepper Servo Motor
- Brand
- JMC Drivers and Motors
- English Name
- JMC 86J18118EC-1000-LS-60-YJ 2-Phase Closed Loop Stepper Servo Motor
- Availability
- In Stock / Made to Order
| Parameter | Specification |
|---|---|
| Frame Size | 86mm (NEMA 34) |
| Step Angle | 1.8掳 (2-Phase) |
| Body Length | 118mm |
| Encoder | 1000 PPR |
| Shaft Diameter | 14mm |
| Shaft Length | 31mm |
| Brake | Yes (Built-in) |
The JMC 86J18118EC-1000-LS-60-YJ is a high-performance NEMA 34 (86mm) 2-phase closed-loop stepper servo motor. It features a 1000-line encoder for full closed-loop control, eliminating step loss and ensuring precise positioning. With a body length of 118mm, it delivers high torque, high speed, and smooth, precise response. The motor includes a built-in brake (YJ) and a square rear cover (LS), making it ideal for CNC routers, laser engraving machines, and automation equipment requiring reliable holding force and high accuracy.
Product Details
Below are the detailed photos and specifications for this item. Contact us on WhatsApp for pricing, stock and matching accessories.
The JMC 86J18118EC-1000-LS-60-YJ is a high-performance NEMA 34 (86mm) 2-phase closed-loop stepper servo motor. It features a 1000-line encoder for full closed-loop control, eliminating step loss and ensuring precise positioning. With a body length of 118mm, it delivers high torque, high speed, and smooth, precise response. The motor includes a built-in brake (YJ) and a square rear cover (LS), making it ideal for CNC routers, laser engraving machines, and automation equipment requiring reliable holding force and high accuracy. Key feature Full Closed Loop: No step loss, low heat generation, and high reliability. High Efficiency & Low Noise: Smooth and quiet operation. High Torque & High Speed: Strong power output for demanding applications. Smooth & Precise: High-speed response with accurate positioning. Precise Rotor & Small Air Gap: Ensures high reliability and consistent performance.
