GDZ-23-2 2.2KW 380v
HQD GDZ-23-2 380v Advertising Woodworking Spindle
- Brand
- HQD Air-cooled Spindles
- English Name
- HQD GDZ-23-2 380v Advertising Woodworking Spindle
- Availability
- In Stock / Made to Order
| Power | 2.2kw |
|---|---|
| Voltage | 380V |
| Current | 8.0A/4.4A |
| Frequency | 400Hz |
| Rotational speed | 24000rpm |
| Tool Holder | ER20 |
| Number of pole | 2P |
| Weight | 6KG |
The HQD GDZ-23-2 is a 2.2 kW water-cooled spindle designed for advertising engraving and woodworking CNC routers. It operates at up to 24,000 rpm with a constant torque of 0.88 Nm and is available in 220V and 380V versions. Equipped with an ER20 collet, it accepts tool shanks from 3.175 mm to 13 mm. The water-cooling system efficiently dissipates heat during continuous operation, while precision P4-grade bearings ensure stable, low-vibration performance on wood, acrylic, and plastics.
Product Details
Below are the detailed photos and specifications for this item. Contact us on WhatsApp for pricing, stock and matching accessories.
The HQD GDZ-23-2 is a 2.2 kW water-cooled spindle designed for advertising engraving and woodworking CNC routers. It operates at up to 24,000 rpm with a constant torque of 0.88 Nm and is available in 220V and 380V versions. Equipped with an ER20 collet, it accepts tool shanks from 3.175 mm to 13 mm. The water-cooling system efficiently dissipates heat during continuous operation, while precision P4-grade bearings ensure stable, low-vibration performance on wood, acrylic, and plastics.
