GDZ-24-1B 3.2kw 380V
HQD GDZ-24-1B 380V Advertising Woodworking Spindle
- Brand
- HQD Air-cooled Spindles
- English Name
- HQD GDZ-24-1B 380V Advertising Woodworking Spindle
- Availability
- In Stock / Made to Order
| Power | 3.2kw |
|---|---|
| Voltage | 380V |
| Current | 12A/7A |
| Frequency | 400Hz |
| Rotational speed | 24000rpm |
| Tool Holder | ER20 |
| Number of pole | 2P |
| Weight | 11.5KG |
The HQD GDZ-24-1B is a 3.2 kW water-cooled spindle designed for heavy-duty woodworking, stone processing, and large-scale material machining. It operates at up to 24,000 rpm with a constant torque of 1.27 Nm and is available in 220V and 380V versions. Equipped with an ER20 collet, it accepts tool shanks from 3.175 mm to 13 mm. The water-cooling system supports S1 continuous-duty operation, making it suitable for long production cycles in demanding engraving and milling environments.
Product Details
Below are the detailed photos and specifications for this item. Contact us on WhatsApp for pricing, stock and matching accessories.
The HQD GDZ-24-1B is a 3.2 kW water-cooled spindle designed for heavy-duty woodworking, stone processing, and large-scale material machining. It operates at up to 24,000 rpm with a constant torque of 1.27 Nm and is available in 220V and 380V versions. Equipped with an ER20 collet, it accepts tool shanks from 3.175 mm to 13 mm. The water-cooling system supports S1 continuous-duty operation, making it suitable for long production cycles in demanding engraving and milling environments.
