前程风冷主轴 GDL70-ISO30-24Z-9.0Long nose
HQD GDL70-ISO30-24Z-9.0 Long Nose ATC Spindle
- 品牌
- 前程风冷主轴
- 英文名称
- HQD GDL70-ISO30-24Z-9.0 Long Nose ATC Spindle
- 库存
- 现货/订货
| Power | 9.0kw |
|---|---|
| Voltage | 220V/380V |
| Current | 32A/20A |
| Frequency | 800Hz |
| Rotational speed | 24000rpm |
| Tool Holder | ISO30 |
| Number of pole | 4P |
| Weight | 31KG |
The HQD GDL70-ISO30-24Z-9.0 is a 9.0 kW air-cooled automatic tool change (ATC) spindle designed for CNC nesting machines and woodworking routers. It operates at up to 24,000 rpm with a 4-pole motor and features an ISO30 tool holder for rapid, automated tool changes. The long-nose design provides extended reach for deep cavity machining and intricate 3D carving. Its independent rear cooling fan eliminates the need for a water-cooling system, reducing maintenance costs while ensuring stable performance during continuous high-speed operation.
产品详情
下面是该产品的详细图片与说明，需要报价、库存或配套方案可以直接 WhatsApp 咨询。
The HQD GDL70-ISO30-24Z-9.0 is a 9.0 kW air-cooled automatic tool change (ATC) spindle designed for CNC nesting machines and woodworking routers. It operates at up to 24,000 rpm with a 4-pole motor and features an ISO30 tool holder for rapid, automated tool changes. The long-nose design provides extended reach for deep cavity machining and intricate 3D carving. Its independent rear cooling fan eliminates the need for a water-cooling system, reducing maintenance costs while ensuring stable performance during continuous high-speed operation.
