HQD前程风冷换刀主轴短款GDL70 24Z 9.0
HQD GDL70-24Z/9.0 short shaft 9.0KW ATC Air-Cooled Spindle Motor – 24000RPM ISO30 for CNC Router
- 品牌
- HQD
- 英文名称
- HQD GDL70-24Z/9.0 short shaft 9.0KW ATC Air-Cooled Spindle Motor – 24000RPM ISO30 for CNC Router
- 库存
- 现货/订货
| Model | HQD GDL70-24Z/9.0 |
|---|---|
| Voltage | 220V |
| Power | 9 KW |
| Current | 32 A |
| Frequency | 800 Hz |
| Speed | 24000 RPM |
| Collet | 26 KG |
| Model (2) | GDL70-24Z9.0 |
| Voltage (2) | 380V |
| Current (2) | 20 A |
| Collet (2) | 26KG |
HQD GDF60-18Z/7.5 is a 7.5KW air-cooled spindle motor designed for CNC router, woodworking engraving, and milling machines. It runs at 18000 RPM with a rated frequency of 300Hz, delivering high torque and stable performance for heavy-duty cutting, drilling, and engraving applications.
产品详情
下面是该产品的详细图片与说明，需要报价、库存或配套方案可以直接 WhatsApp 咨询。
HQD GDF60-18Z/7.5 is a 7.5KW air-cooled spindle motor designed for CNC router, woodworking engraving, and milling machines. It runs at 18000 RPM with a rated frequency of 300Hz, delivering high torque and stable performance for heavy-duty cutting, drilling, and engraving applications. The spindle features an ER32 collet, grease-lubricated bearings, and high-precision angular contact ball bearings (2×7008C P4 / 2×7003C P4), ensuring low vibration, high accuracy, and long service life. Air-cooled design eliminates the need for a water cooling system, making it easier to maintain and suitable for dusty working environments. Available in both 220V (26.0A) and 380V (15.0A) versions. Ideal for heavy-duty woodworking CNC routers, advertising engraving machines, and general non-metal milling equipment. Wholesale and bulk orders supported
