杰美康驱动器和电机 jmc Microstep driver 2DM860
JMC 2DM860 2-Phase Digital Stepper Drive for CNC Router
- 品牌
- 杰美康驱动器和电机
- 英文名称
- JMC 2DM860 2-Phase Digital Stepper Drive for CNC Router
- 库存
- 现货/订货
| Parameter | Specification |
|---|---|
| Input Voltage | DC 30V-110V / AC 24V-80V |
| Continuous Current | 7.5A (20KHz PWM) |
| Max Pulse Frequency | 200K |
| Default Baud Rate | 57.6Kbps |
| Protection | Over-current: 12A ±10% (Peak) |
| Dimensions (mm) | 150 x 97.5 x 53 mm |
| Weight | Approx. 580g |
| Operating Temp | 0 ~ 70°C |
| Storage Temp | -20 ~ +80°C |
| Humidity | 40 ~ 90% RH |
| Cooling Method | Natural cooling or forced air cooling |
| Environment | Avoid dust, oil mist, and corrosive gases. Indoor use only. |
The JMC 2DM860 is a high-performance 2-phase digital stepper drive designed for precision motion control. It features advanced current vector control and built-in acceleration/deceleration functions, making it perfectly suited for CNC routers, engraving machines, and automation equipment. It offers smooth low-speed operation, low heat generation, and automatic motor parameter tuning.
产品详情
下面是该产品的详细图片与说明，需要报价、库存或配套方案可以直接 WhatsApp 咨询。
The JMC 2DM860 is a high-performance 2-phase digital stepper drive designed for precision motion control. It features advanced current vector control and built-in acceleration/deceleration functions, making it perfectly suited for CNC routers, engraving machines, and automation equipment. It offers smooth low-speed operation, low heat generation, and automatic motor parameter tuning. Key feature Auto-tuning & Self-adaptation: Parameters are automatically tuned to match the motor. High Subdivision: Built-in high micro-stepping for smooth, low-vibration, and low-heat operation. Torque Compensation: Mid and high-speed torque compensation for consistent performance. Current Vector Control: High current efficiency and precise control. Built-in Accel/Decel: Smooth start and stop control. Position Memory: Motor running position memory function. Signal Isolation: Differential optically isolated input signals, compatible with 5V~24V. Customizable Micro-stepping: User-defined subdivision settings. Protection: Over-current and over-voltage protection. Auto-detection: Flexible pulse edge counting selection. LED Indicators: Green LED for running status, Red LED for protection or stall alarm.
